Orbo-Lok Sand Screen Pad/Disc Driver
The Malish ORBO-LOK 17″ Sanding Screen Pad/Disc Driver with P-200 Clutch Plate is an innovative floor machine accessory that transforms a standard rotary floor machine into a high-efficiency orbital motion sander. Unlike conventional drivers, ORBO-LOK’s unique design delivers orbital motion that helps minimize back-swirl marks and improve sanding consistency — especially when used with a loose weave pad and sanding screen.
Included with this driver is a P-200 universal clutch plate, engineered to fit most standard floor machines on the market, making it versatile for a wide range of machine brands and types. The ORBO-LOK system enhances dust control as the pad absorbs particles, reducing airborne debris and keeping your workspace cleaner. This accessory is especially valuable for floor sanding, surface prep, and refinishing applications where orbital sanding motion delivers smoother results with less effort.
Made in the USA, the ORBO-LOK is built for durability and long-lasting performance in demanding environments.
- 17″ ORBO-LOK orbital sanding screen pad/driver with P-200 clutch plate
- Converts standard floor machines into orbital motion sanders
- Reduces back-swirl marks compared to conventional sanding
- Use with a loose weave pad (white or red recommended) and sanding screen
- Includes P-200 universal clutch plate — fits most standard floor machines
- Improved dust absorption via pad to reduce airborne debris
- Ideal for floor sanding, surface preparation, and refinishing tasks
- Made in the USA
- Product Name:
- Malish ORBO-LOK Sanding Screen Pad Driver
- Model:
- 782217
- Diameter:
- 17″ (Driver Block)
- Type:
- Sanding Screen Pad/Disc Driver
- Included Clutch Plate:
- P-200 Universal Clutch Plate
- Machine Compatibility:
- Most standard floor machines via universal clutch plate
- Recommended Use:
- Orbital sanding, surface prep, refinishing
- Country of Origin:
- USA
Determining Diameters
Block Diameter: Lay the brush on the bristles, block side up. Measure the actual outside diameter of the block (not the bristle flare). See photo below for reference (measurement B).
Center Hole Diameter: Lay the brush on the bristles block side up. Remove mounting hardware, if any. Measure actual inside diameter of the center hole. See photo below for reference (measurement D).
NOTE: Malish brushes are designed to fit each machine as shown, even though the block diameter listed on the charts may vary slightly from the diameter of the block originally supplied with the machine.
How to Break in a New Floor Machine Brush
Before using a new brush on carpeting, the brush should be broken in according to the following directions. This will eliminate possible excess drag by “tipping” the strands, removing any possible burrs caused by the manufacturing process.
Break-in Procedure
- Mount the brush on the floor machine. Follow ALL instructions included in your owner's manual.
- Find a rough textured floor surface, preferably unfinished concrete.
- Operate the machine on this surface. Run the machine DRY for approximately 15-20 minutes. The brush fibers will take a slight set or lean in the direction of machine rotation.
- Rinse the brush to remove any dirt caught when running machine. The brush is now ready to be used on carpeting.
Do you want a brush or a pad driver?
If your preference is to have a dedicated product, select a brush. If you have a variety of applications, your choice may be a pad holder. The surface being cleaned and the amount of dirt build-up will help determine the selection. The key to remember when ordering these items is the block diameter in relationship to the machine size. A brush is sized 2 inches smaller than the machine because of the flare of the brush fibers. Pad drivers are specified 1 inch smaller than the machine.
There is an easy way to cross check your selection from the Floor Machine Brushes and Clutch Plates section of this web site.
- A brush, long-trim pad driver, or short-trim pad driver without a riser, should be 2" smaller than the machine size.
- A pad driver or MIGHTY-LOK™ should be 1" smaller than the machine size.
Therefore, a 20" floor machine would use an:
- 18" brush, MAL-LOK™ or PAD-LOK™ without a riser
- or a 19" PAD-LOK™ or MIGHTY-LOK™
This rule applies to over 90% of the applications.
